Please ensure your current remote is pictured in the main image and your remote has a green light.Coding the new remote can be completed by either using an old working remote or if no working remote is available you willrequire two peopleas you will need to remove the negative terminal from the battery and replace it but the next step must be done within 10 seconds.

Compatible with:

• TX22B
• VAE 315-950
• VAE 317-490
• AB950

Instructions:

1. Sit in drivers seat with drivers door open
2. Lock and unlock doors with existing remote (if no existing remote, disconnect the negative battery terminal for 30 seconds, reconnect negative battery terminal, and start from step 3)
3. Turn key from Accessories to On 20 times within 12 seconds, and return the key back to Off
4. Hazards should flash 20 times to indicate programming mode (if this step does not occur you must start again from step 1 – Also if it still does not flash please try step 3 but turning the key from OFF to ON instead of Accessories to ON)
5. After the 20th flash press the remote control
6. Hazards should flash once to indicate successful registration
7. Press any additional and existing remotes (max 3)
8. Turn key from On to Off twice
9. Remove key, exit vehicle and test all remotes.
