System Requirements
PC with Windows XP or Windows Vista? or Windows 7
USB Port
This product is compatible with PLAYSTATION 3.
GOOGLE TV

Warranty Information
3-year limited hardware warranty with Logitech

Package Contents

Logitech diNovo Mini?
USB Mini-receiver
Power adapter
CD with software, comfort guidelines and help center
User?s guide
Cleaning cloth
Full product support

• Technical Specifications

• 25 mm (.98-inch) dual-purpose ClickPad. Works as a touch pad and a 4-way directional pad
• Thumb-operated keypad design
• 63 backlighted keys
• Backlighting for two modes?orange for touch-pad mode, green for media-center remote mode
• Ambient light sensor measures current available light and turns off backlight, if necessary, to conserve power
• Troy gloss silver with midnight black design
• Dedicated Windows Media Center button
• Range: up to 10 m (33 feet)

Connectivity

• Bluetooth 2.0 wireless technology
• Point-to-point technology pre-paired with DiNovo Mini keyboard. (Does not act as a hub.)

Power and Battery

• 30 days (battery life)
• Full-charge: Takes about 4 hours.
• Fast-charge: Takes about 10 minutes for 1 day of use
• 950 mAH lithium-ion battery
• Dimensions and Weight
• 152 x 90 x 27.5 mm (cover closed) (5.98 x 3.5 x 1.08-inch)
• 152 x 153 x 65 mm (cover opened) (5.98 x 6 x 2.55-inch)
• 170-175 g (with battery and receiver) (5.99 ? 6.17 oz)
• 59.5 x 18.5 x 9.1 mm (receiver size) (2.34 x 0.73 x 0.36-inch)
• 7 g (receiver weight) (0.25 oz)
